100 Mile Long Distance POC LTE Handheld Radio Walkie Talkie
This long-distance POC LTE handheld radio combines wide-area 4G push-to-talk communication with 5W analogue radio capability. It is designed for security teams, logistics operations, construction sites, transportation fleets and other organisations that require fast group communication across different locations.
- Communication: 4G LTE POC plus analogue two-way radio
- LTE Bands: B1 / B3 / B5 / B8 / B34 / B38 / B39 / B40 / B41
- Analogue Frequency: 136–174MHz / 350–400MHz / 400–470MHz
- Analogue Output Power: 5W
- Battery: 4000mAh, up to 29 hours standby
- Display: 1.77-inch screen
- Protection: IP54
- Charging: USB Type-C
- GPS Positioning: Optional
Long-Distance 4G POC and Analogue Two-Way Radio
The 100 Mile Long Distance POC LTE Handheld Radio is designed for organisations that need instant push-to-talk communication between employees working in different buildings, districts, cities or operational areas. When connected to a supported 4G network and the POC Global platform, users can communicate without being restricted by the short point-to-point range of a conventional handheld radio.
In addition to LTE POC communication, the radio supports 5W analogue operation in selected VHF and UHF frequency ranges. This dual communication capability makes it suitable for customers that need wide-area cellular communication while retaining access to local analogue radio channels.
Is This Radio Suitable for Your Operation?
This model is recommended for businesses that need to connect employees across a wider area than conventional handheld radios can normally cover. It can be used for local team communication, regional coordination and centralised group calling through a compatible POC platform.
Recommended Users
- Security companies and guard patrol teams
- Warehouses and logistics operators
- Construction and engineering contractors
- Transportation and fleet operators
- Hotels, resorts and property management teams
- Dealers, distributors and system integrators
“`
Recommended Requirements
- Communication between different sites or districts
- Fast one-to-one and group coordination
- Loud audio for outdoor or noisy workplaces
- Optional GPS-based personnel positioning
- Long working shifts and Type-C charging
- Local analogue communication as a backup or supplementary mode
“`
Key Features and Operational Benefits
Wide-Area Communication Through 4G LTE
The radio uses supported 4G LTE networks to transmit PTT voice traffic through the POC Global platform. Employees can communicate across different operational locations as long as their radios are connected to an available mobile network and activated on the same compatible platform.
Supported LTE bands include B1, B3, B5, B8, B34, B38, B39, B40 and B41. Network compatibility should be confirmed according to the SIM card, mobile operator and destination country before ordering.
Automatic 4G Network Switching
The radio is designed to maintain POC connectivity across supported 4G network bands. When network conditions change, the device can switch or reconnect through an available supported LTE connection, helping mobile employees remain connected while moving between coverage areas.
POC and 5W Analogue Communication
In addition to network-based POC communication, the handheld radio supports 5W analogue transmission. Available analogue frequency versions include 136–174MHz, 350–400MHz and 400–470MHz.
The correct frequency version must be selected according to the customer’s existing radios, local frequency regulations, licensed channels and intended operating environment.
Loud, High-Fidelity Audio
The large-volume audio output is intended to improve voice clarity in warehouses, construction areas, transportation environments and other workplaces with elevated background noise. High-fidelity audio reproduction helps users understand messages quickly without repeatedly requesting the caller to transmit again.
Group Call, Individual Call and Friend Management
The POC communication system supports group calls, individual calls and contact or friend management. Administrators can organise users according to department, project, location or job role, helping reduce unnecessary radio traffic between unrelated teams.
PTT Voice Rights Application and Preemption
PTT floor-control functions allow users to request speaking rights before transmitting. Voice-right preemption can help authorised personnel, supervisors or priority users take control of an active talk group when urgent instructions need to be delivered.
Exact priority levels, permissions and preemption behaviour depend on the selected POC platform configuration and account administration settings.
Optional GPS Positioning
An optional GPS version is available for customers that need location-based personnel or fleet management. GPS information may be used with compatible platform functions for location display, dispatching or operational supervision.
GPS tracking functions must be confirmed together with the selected radio version, POC platform and dispatch software.
4000mAh Battery and USB Type-C Charging
The 4000mAh battery supports extended daily operation and provides a specified standby time of up to 29 hours under the manufacturer’s test conditions. Actual operating time varies according to PTT usage, LTE signal strength, screen activity, GPS operation, volume level and network conditions.
USB Type-C charging provides a convenient charging interface for offices, vehicles, warehouses and mobile work locations.
1.77-Inch Display
The 1.77-inch screen allows users to view important operating information, such as contacts, groups, network status and selected communication functions, depending on the installed software and platform configuration.
IP54 Protection
The IP54-rated enclosure provides protection against limited dust ingress and water splashes during normal commercial use. It is suitable for many indoor and light outdoor applications but should not be treated as fully waterproof or submerged in water.
Industry Applications
Security and Guard Patrol
Connect guards, supervisors and control-room personnel across buildings, commercial properties or multiple patrol locations. Group calling supports routine coordination, while individual calling can be used for private operational instructions.
Warehousing and Logistics
Coordinate loading teams, drivers, warehouse staff and logistics supervisors across separate facilities or delivery routes. The loud audio output is suitable for environments where machinery and vehicle noise can make normal mobile-phone calls difficult to hear.
Construction and Engineering
Support communication between project managers, site supervisors, equipment operators and mobile teams. The POC function can connect different project areas, while the analogue mode may be used for local radio channels where appropriate.
Transportation and Fleet Operations
Provide one-button voice communication between dispatchers, drivers and fleet supervisors without requiring users to dial telephone numbers. The optional GPS version can support location-related dispatch functions when used with a compatible platform.
Hotels, Resorts and Property Management
Create separate communication groups for security, engineering, housekeeping, transport and management personnel. POC communication is useful when staff work across a large property or between separate buildings.
Technical Specifications
| Item | Specification |
|---|---|
| Product Type | POC LTE and analogue handheld two-way radio |
| Network | 4G LTE |
| LTE Bands | B1 / B3 / B5 / B8 / B34 / B38 / B39 / B40 / B41 |
| POC Platform | POC Global |
| Analogue Frequency Options | 136–174MHz / 350–400MHz / 400–470MHz |
| Analogue RF Output Power | 5W |
| Display | 1.77-inch screen |
| Battery Capacity | 4000mAh |
| Standby Time | Up to 29 hours under specified test conditions |
| Charging Interface | USB Type-C |
| Ingress Protection | IP54 |
| GPS | Optional |
| Call Functions | Group call, individual call and friend/contact management |
| PTT Management | Voice-right application and preemption |
Specifications, supported functions and platform behaviour may vary according to hardware version, firmware, SIM card, frequency configuration and POC account settings.
POC Platform, SIM Card and Service Requirements
POC communication requires more than the radio hardware. Buyers should confirm the complete operating arrangement before placing a bulk order.
- SIM Card: A compatible 4G SIM card and active mobile data service may be required.
- POC Account: Each radio may require platform registration, an account or device activation.
- Platform Fees: Server, account or subscription charges should be confirmed during quotation.
- Group Configuration: User groups, individual contacts and permissions should be configured before deployment.
- GPS Functions: Location display requires the GPS version and compatible platform support.
- Network Coverage: POC communication is unavailable in locations without suitable mobile data coverage.
Package and Accessory Configuration
Exact package contents depend on the selected version and quotation. A typical supply configuration may include the handheld radio, battery, antenna, belt clip, USB Type-C charging cable, power adapter and user documentation.
Optional GPS, compatible audio accessories, spare batteries and charging solutions can be discussed according to the project requirements. All included items and accessory compatibility will be confirmed before the order is finalised.
Quality Checks Before Shipment
Before bulk deployment, customers should confirm the radio version, LTE compatibility, analogue frequency and platform configuration. Pre-shipment inspection can cover the following functions according to the ordered configuration:
- Power-on and screen operation
- 4G network registration
- POC platform login and PTT communication
- Group-call and individual-call functions
- Analogue transmit and receive testing
- Speaker volume and audio output
- Battery charging and Type-C interface
- GPS positioning when the optional GPS version is ordered
Procurement Information
| Procurement Item | Available Terms |
|---|---|
| MOQ | 2 sets |
| Sample Order | Available for product and network compatibility evaluation |
| Bulk Pricing | Quoted according to quantity, configuration and accessories |
| Payment | T/T or Credit Card |
| Shipping Terms | EXW / FOB / FCA / DAP / DDP |
| Freight Forwarder | Shipment to the customer’s appointed freight forwarder is accepted |
| Lead Time | Confirmed according to stock status, quantity and configuration |
| Warranty | 1-year quality-issue replacement service, excluding damage caused by misuse |
The final quotation should clearly state the radio version, LTE bands, analogue frequency, GPS option, package contents, platform service, SIM arrangement, accessories, lead time and shipping method.
Frequently Asked Questions
Does this radio have a fixed 100-mile communication range?
POC communication uses the 4G mobile network and can connect users over much longer distances when both radios have suitable network coverage and active platform access. The analogue communication range is significantly shorter and depends on terrain, buildings, antennas and local interference.
Does the radio require a SIM card?
A compatible SIM card and mobile data service may be required for 4G POC communication. SIM compatibility and data arrangements should be confirmed for the destination market.
Is the POC platform included with the radio?
Platform activation, user accounts, server access and any applicable service fees should be confirmed in the quotation. Hardware and platform service may be supplied or billed separately depending on the project.
Can it work as a normal analogue walkie-talkie?
Yes. The radio supports 5W analogue communication in the selected 136–174MHz, 350–400MHz or 400–470MHz version. Frequency compatibility and local regulations must be confirmed before use.
Which frequency version should I order?
Please provide the frequency used by your existing radios, the destination country and the intended application. The correct VHF, mid-band or UHF version can then be recommended.
Does every version include GPS?
No. GPS is optional and must be specified when requesting a quotation. Platform support for location display should also be confirmed.
Can I order one unit for testing?
Yes. The minimum order quantity is one set. A sample order is recommended to verify LTE network compatibility, platform functions, analogue frequency and audio performance before a larger deployment.
What information is required for a quotation?
Please provide the required quantity, destination country, mobile operator, analogue frequency, GPS requirement, application, preferred accessories and shipping method.
